Elite Attachments

Our Products


Elite Attachments Australia offers a comprehensive range of automatic quick hitches to suit machines of all shapes and sizes. From 2.5T to 45T and beyond, Elite Attachments Australia offers an Auto Lockā„¢ to suit your needs!


Machine Size AutoLOCK Hitch Model Brand Hitch Standard Base Width (mm) Pickup Centre Range (mm) Hitch Mass (kg) Lifting Lug Capacity (tonne) Front/Rear Pin DIA (mm) Box Size
2.5T EL25AL-35/118 KOB, HYU, HIT, KOM* 118 165-200 35.3 SWL 1.5T 35 B3
3T EL30AL-35/130 JCB 130 125-130 31 SWL 1.5T 35 B3S
3.5T (HD) EL35AL-38/141 YAN 120 165-215 50.7 SWL 1.5T 37.75 B3Y
3.5T EL35AL-40/154 JCB 154 295-350 36.4 SWL 1.5T 40 B4J
4T EL40AL-40/120 KOB, HYU, VOL, HIT, KOM* 120 165-220 43.5 SWL 2.0T 40 B4
4.5T EL45AL-45/160 JCB 160 295-345 71.4 SWL 2.0T 44.45 B5J
5T EL50AL-45/140 KOB, HYU, VOL, HIT, KOM* 140 210-290 63 SWL 2.5T 45 B5
5T (HD) EL55AL-45/165 YAN 140 210-285 81 SWL 2.5T 45 B5Y
8T EL80AL-50/154 KOB, HYU, VOL, HIT, KOM* 154 245-320 95.2 SWL 3.0T 50 B6
8T EL80AL-55/184 HYU 184 245-320 95.2 SWL 3.0T 55 B6
8T EL80AL-60/164 VOL 164 260-315 95.2 SWL 3.0T 60 B6
13T EL140AL-65/248 KOB, HYU, VOL, HIT, KOM* 248 350-410 182.5 SWL 6.0T 65 B7
20T EL200AL-80/300 KOB, HYU, VOL, HIT, KOM* 300 420-530 395 SWL 9.0T 80 B9
25T EL250AL-90/320 KOB, HYU, VOL, HIT, KOM 320 440-540 425 SWL 10.0T 90 B9
35T EL350AL-90/374 KOB, HYU, VOL, HIT, KOM* 374 450-580 502.3 SWL 14.0T 90 B10
45T EL450AL-100/400 KOB, HYU, VOL, HIT, KOM* 400 490/615 900 SWL 20.0T 100 B11
